| Present Location |
Glouc Warks |
| Designed For |
GWR |
| Type & Original Water Capacity (gallons) |
Collett 3000 gallon |
| Original Coal Capacity (tons) |
4.25 |
| Chassis Type |
Collett 3 axle (later type) |
| Wheelbase |
7ft 6in + 7ft 6in |
| Gauge |
4ft 8 1/2in |
| Current Water Capacity (gallons) |
3000 |
| Current Coal Capacity (tons) |
4.25 |
| Scoop Fitted |
No |
| Allocated To |
2807 GWR 28XX class 2-8-0 |
| First Number |
3002 |
| Present Number |
3002 |
| Owner |
2251 Locomotive Fund |
| Status |
Under Restoration / Overhaul |
| Additional Notes |
Tank has not been replaced since preservation. This tender is normally coupled with GWR class 2251 0-6-0 no 3205 but is on hire to the Cotswold Steam Preservation Ltd for use with GWR 28XX class 2-8-0 no 2807 |
| Main Photo Taken By |
Justin Edwards |
| Date of Image |
05/08/2015 |
| Record Last Updated |
08/08/2023 |
